380V High EER Air Cooler Chiller 340 Tons With R134A Refrigerant

380V High EER Air Cooler Chiller 340 Tons With R134A Refrigerant

    • 380V High EER Air Cooler Chiller 340 Tons With R134A Refrigerant
    • 380V High EER Air Cooler Chiller 340 Tons With R134A Refrigerant
  • 380V High EER Air Cooler Chiller 340 Tons With R134A Refrigerant

    Product Details:

    Place of Origin: China
    Brand Name: EuroKlimat
    Certification: ISO9001, ISO14001, OHSAS18001, CRAA, CQC
    Model Number: EKAS340AR3XE

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 pcs
    Price: negotiation
    Packaging Details: Plywood
    Delivery Time: 40 working days after received your payment
    Payment Terms: L/C, T/T
    Supply Ability: 60pcs per month
    Contact Now
    Detailed Product Description
    Cooling Capacity(kW): 1239 Heating Capacity(kW): 1179
    Cooling Power Input(kW): 353 Heating Power Input(kW): 348
    Power Supply: 380V/3~/50Hz Compressor Type: Semi-hermelic Dual-screw Compressor



    380V High EER Air Cooler Chiller 340 Tons With R134A Refrigerant





    EK keeps looking for valuable distributors and partners around international markets…



    General Specifications



    Chiller Manage System (Optional)- EK provide intelligent CMS for centralized control on several air cooled screw chillers to balance each unit running time ,and perform automatically switchover on a fault unit , ensuring the whole system stable running & energy saving .



    Capacity Continuous Adjustment -With intelligent controller , EK chiller performs a prompt adjustment according to system load to ensure the precisely chilled water temperature . What’s more , it will unload automatically at extremely high ambient temperature to protect compressor.



    Environmental Friendly-EKAS is an air cooled screw chiller which use dual screw compressor with R134a refrigerant



    High Efficiency-The “Apollo”/“Apollo+” stands for high efficiency/ extremely high efficiency on partial and full load operation , thanks to dual screw compressor , sub-cooling design , M shape condenser ,economizer , shell and tube evaporator ,electronic expansion valve and patent aerofoil aluminum fan .





    10.1” Touch Screen -is directly connected to the microprocessor , providing monitoring history data recording ,safety protection ,and more convenient operation .



    Widely Applications -EKAS is the idea solution for commercial building & industrial applications that required high performance ,continuous operation , lower operation and maintenance cost .



    BMS (Optional)-EK provide an RS485 standard communication interface , which is more convenient to joint with building management system . Standard protocol includes BacNet ,Modbus and Lonwork .
